Parametric Search Selector
Part Number
Images
Frequency Range (MHz)
Psat (dBm)
P-1 (dBm)
Gp (dB)
Work Efficiency η（%）
Vd(d)
Gain Flatness
Mode
Pulse indicators
Package
Status
MCNI011013-P40
MCNI011013-P40
1100-1300
40
14
50
28
±0.8
CW
IK-2
MCNI011016-P49
MCNI011016-P49
1100-1600
49
10
50
28
±0.8
CW
IH
MCNI012014-P40
MCNI012014-P40
1200-1400
40
14
50
32
±0.8
CW
IK-2
MCNI012014-P43
MCNI012014-P43
1200-1400
43
14
60
28
±0.8
CW
IK-2
MCNI012014-P48
MCNI012014-P48
8500-9600
48
13
50
32
±0.8
CW
IK
MCNI012014-P51
MCNI012014-P51
1200-1400
51
13
50
32
±0.8
CW
IK
MCNI012014-P51.5
MCNI012014-P51.5
1200-1400
51.5
13
50
50
±0.8
Pulse
T=1ms, Duty=20%
IK-2
MCNI012014-P52
MCNI012014-P52
1200-1400
52
13
55
50
±0.8
Pulse
T=1ms, Duty=10%
IK-2
MCNI012014-P53
MCNI012014-P53
1200-1400
53
13
50
28
±0.8
Pulse
IK
MCNI012014-P56
MCNI012014-P56
1200-1400
56
13
50(Type)
50
±0.8
Pulse
JF06F016
MCNI012014-P57
MCNI012014-P57
1200-1400
57
16
55
50
±0.8
Pulse
T=1ms, Duty=10%
IH
MCNI012016-P46
MCNI012016-P46
1200-1600
46
11
55
28
±0.8
CW
IK-2
