Parametric Search Selector
Part Number
Images
Frequency Range (MHz)
Psat (dBm)
P-1 (dBm)
Gp (dB)
Work Efficiency η（%）
Vd(d)
Gain Flatness
Mode
Pulse indicators
Package
Status
MCNI013015-P36
MCNI013015-P36
1300-1500
36
14
30
28
±0.8
CW
IJ
MCNI013015-P44
MCNI013015-P44
1300-1500
44
14
50
28
±0.8
CW
IK-2
MCNI013015-P46
MCNI013015-P46
1300-1500
46
12
50
28
±0.8
CW
IK
MCNI013018-P37
MCNI013018-P37
1300-1800
37
14
55
28
±0.8
CW
IJ
MCNI013018-P40
MCNI013018-P40
1300-1800
40
12
55
28
±0.8
CW
IK-2
MCNI013018-P43
MCNI013018-P43
1300-1800
43
13
55
28
±0.8
CW
IK-2
MCNI013018-P46
MCNI013018-P46
1300-1800
46
13
50
28
±0.8
CW
IK-2
MCNI013018-P47
MCNI013018-P47
1300-1800
47
12
50
28
±0.8
CW
IK-2
MCNI013018-P49
MCNI013018-P49
1300-1800
49
11
55
28
±0.8
CW
IH
MCNI013018-P50
MCNI013018-P50
1300-1800
50
10
55
28
±0.8
CW
IH
MCNI013018-P51
MCNI013018-P51
1300-1800
51
10
55
32
±0.8
CW
IH
MCNI013018-P53
MCNI013018-P53
1300-1800
53
9.5
55
48
±0.8
Pulse
T=100us,Duty=10%
IH
