Home
GaAs IMFET
GaAs IMFET
View All Products
RF Products
Internal-Matched Amplifiers
GaN IMFET
GaAs IMFET
Pre-Matched Amplifiers
GaN Pre-Matched Amplifiers
Power Amplifier MMICs
GaN PA (Package）
GaN PA(Die)
GaAs PA (Package）
GaAs Saturated PA (Die）
GaAs Single-Supply PA (Die)
GaAs Linear PA (Die)
Drivers
GaAs Drivers ( Package)
High Power Switch
High Power Switch
GaAs IMFET
RF Products
Internal-Matched Amplifiers
GaN IMFET
GaAs IMFET
Pre-Matched Amplifiers
GaN Pre-Matched Amplifiers
Power Amplifier MMICs
GaN PA (Package）
GaN PA(Die)
GaAs PA (Package）
GaAs Saturated PA (Die）
GaAs Single-Supply PA (Die)
GaAs Linear PA (Die)
Drivers
GaAs Drivers ( Package)
High Power Switch
High Power Switch
Parametric Search Selector
Part Number
Images
Frequency Range (MHz)
Psat (dBm)
P-1 (dBm)
Gp (dB)
Work Efficiency η（%）
Vd(d)
Gain Flatness
Mode
Package
Status
MCCI058064-P42
MCCI058064-P42
5800-6400
42
8.5
38
10
±0.8
CW
IK
MCCI058067-P36-1
MCCI058067-P36-1
5800-6700
36
10
40
10
±0.8
CW
IB
MCCI058067-P39-1
MCCI058067-P39-1
5800-6700
39
10
35
10
±0.8
CW
IB
MCCI058067-P41-1
MCCI058067-P41-1
5800-6700
41
10
38
10
±0.8
CW
IK
MCCI058067-P45-1
MCCI058067-P45-1
5800-6700
45
10
35
10
±0.8
CW
IK
MCCI05850642-P45
MCCI05850642-P45
5850-6425
45
8
30
10
±0.8
CW
IK
MCCI059064-P36-1
MCCI059064-P36-1
5900-6400
36
10
40
10
±0.8
CW
IB
MCCI059064-P36.5-1
MCCI059064-P36.5-1
5900-6400
36.5
10
37
10
±0.8
CW
IB
MCCI059064-P39-1
MCCI059064-P39-1
5900-6400
39
9
40
10
±0.8
CW
IB
MCCI059064-P39.5-1
MCCI059064-P39.5-1
5900-6400
39.5
10
37
10
±0.8
CW
IB
MCCI059064-P42.5-1
MCCI059064-P42.5-1
5900-6400
42.5
10
40
10
±0.8
CW
IK
MCCI059064-P45
MCCI059064-P45
5900-6400
45
8.5
38
10
±0.8
CW
IK
«Previous
1
2
3
4
5
...
6
7
8
Next»
